Testing and Troubleshooting
Introduction
This section contains testing and troubleshooting information and procedures. Repair of the H12+ is limited.
Removal of the label on the rear of the H12+ can and will void any and all Manufacturer's Warranties, see Warning.
WARNING: No user serviceable parts are inside. Any modification of this device will void any and all
Manufacturer's Warranties and/or responsibilities. If you are not able to correct the H12+
Digital Recorder questionable operating state using the Troubleshooting guide in this
manual, do not attempt to service it yourself. Contact Mortara Technical Support if
servicing assistance is needed.
Conformance Test
Conformance testing is to be performed by Authorized Mortara Service Representatives to verify
the device is functioning correctly after repair operations have been performed. Testing results
should be documented on the test data record (TDR) at the end of this section of the manual.
1.0 Test Description
This document describes the steps necessary to functionally test the H12+ Recorder.
2.0 Definition of Terms
UUT Unit Under Test
DMM Digital Multi-Meter
LCD Liquid Crystal Display
CF Compact Flash
