Attaching the Patient Cable
The LeadForm Patient Cable consists of a connector block, main cable and ten leadwires connected to the main
cable. Each leadwire terminates in a snap connector. The leadwires are positioned on the main cable to follow the
contour of the torso.
Insert the connector block into the input connector on the side of the H12+.
Note: Be careful to insert the connector block parallel to the input connector of the H12+.
