_ _ _ Section 5
5-1
5
Printed Circuit Boards
Introduction
This section provides illustrations of the H12+ Holter Recorder Printed Circuit boards. The parts list has not been
provided. Boards are to be ordered for replacement as a whole. Refer to Safety Test in the section for Testing and
Troubleshooting.
Anti-Static equipment should always be worn when working with
static sensitive devices and in a static sensitive area.
Flow chart
The following flow chart shows the way that the data is received and stored into the H12+
