Motion iWMC Series User Manual

Moon Control Products Ltd. Tel.: +44 (0)1202 599922 www.mooncontrolproducts.com Page | 35
Response registers:
Staon No.
Funcon code
Modbus address
Data length (word)
CRC
High byte
Low byte
1 byte
10
2 bytes
1 byte
1 byte
2 bytes
Note
If there is error such as address over range, non-exist address and the address is read only, then it will
return funcon code 0x90.
For example: send message 01 10 6F 00 00 02 04 55 55 00 08 1A 47
Meaning: 01——ID No.;
10——funcon code, write mulple WORD;
6F 00——WORD Modbus address for wring data. This is the address corresponding to parameter
“Target Velocity” (60FF0020) , data length 2;
00 02——write 2 WORD;
04——data length 4 bytes (2*WORD);
55 55 00 08——write data 00085555 (HEX) , 546133 (OCT) , convert to 200RPM;
1A 47——CRC check.
6.5 Modbus Message Example
Under dierent modes, message is sent when staon No. is 1:
Table 6-2 485 message
Internal
address
Name
Meaning
Message (ID=1)
3500
Operaon_mode
Operatemode is 3
010635 0000 03C6 07
6F00
Targte_Speed
Speed 150RPM
01106F 0000 020455 5500 081A 47
3100
Controlword
Enable F
010631 0000 0FC7 32
3200
Status word
Read register status
01 03 32 00 00 02 CA B3
