Motorola APX 2000 Detailed Service Manual

Troubleshooting Charts: TX Audio Error 5-31
External Mic Failure
TX Audio error
External MIC
Follow TX Audio
Error - Side MIC
Failure
Measure Audio Signal at Keypad
Board R2003
Test Internal Side MIC
Audio Signal
present?
Examine Keypad and Main
Board connectors.
Audio signal present?
Replace Backit Flex.
Measure MIC Bias at
R6404
Internal Side
MIC functional
Is Connector
Demaged or Soldered
improperly
Measure Audio at CODEC
C6404 Capacitor
Replace Connector
Replace Housing
and GCAI Flex
Check TX_DA thru R2817.
If no signal check CODEC
circuitry.
4.5 < V < 4.9
Inspect MIC Bias
circuit U6402 and
Supporting Circuitry
Parts Solder and
Placement Correct?
Is SSI Audio
Data Present
View SSI Signals at R2807
and R2808 using
Oscilloscope.
Check CODEC
or OMAP
Replace U6402
Replace parts
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
No
No
No
No

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
