Motorola APX 2000 - Recommended Service Tools; Table 4-1. Recommended Service Tools

4-2 Troubleshooting Procedures: Recommended Service Tools
4.2 Recommended Service Tools
Table 4-1 lists recommended service tools that can be used for PC board repairs at the component
level. For listings of additional service tools, service aids, and test equipment that are recommended
for all levels of service, refer to the APX 2000/ APX 4000/ APX 1000 (900 MHz) basic service manual
(see “Related Publications” on page vii).
NOTE: Do not place an order for the Programming Cable (PMKN4012A/PMKN4013B) as it is not compatible
with the APX 2000/ APX 4000/ APX 4000Li/ APX 1000 (900 MHz) radio.
Table 4-1. Recommended Service Tools
Motorola
Part Number
Description Application
66012028001 Chassis Opener Used to disassemble chassis from housing
66012031001 Battery Adapter Used in place of battery to connect radio to an external
power supply.
66012030001 Vacuum Test Fixture Connects the vacuum/pressure hose to the radio.
NLN9839_ Vacuum Pump Kit Vacuum pump with gauge and vacuum hose. Requires
66012030001 Vacuum Test Fixture.
5880384G68 SMA to BNC Adapter Adapts radio’s antenna port to BNC cabling of test
equipment.
RVN5224_ Customer Programming Software
(CPS) and Tuner Software
CPS allows customer-specific programming of modes and
features. Tuner software required to perform alignment of
radio parameters.
PMKN4012B Programming Cable Used to program the radio through Customer
Programming Software and Tuner Software.
PMKN4013C Programming/Service Cable Used to program and service the radio through Customer
Programming Software and Tuner Software.
RLN4460_ Portable Test Set Used for radio performance checks. Connects to radio’s
universal connector and allows remote switching and
signal injection/outputs for test equipment measurements.
