Motorola APX 2000 Detailed Service Manual

5-32 Troubleshooting Charts: Keyload/Secure Hardware/Memory
5.13 Keyload/Secure Hardware/Memory
Keyload Failure
KEYLOAD FAILURE
Synopsis
This failure relates to only secure equipped radios
and indicates a failure to load key with the KVL
indicated by the message “KEYFAIL” and keyfail
tones.
Typical failures would be :
1) Open between the GCAI connector and the
microprocessor which prevents the keyloading.
2) Use of the wrong KVL or keyload cable.
3) Failure of the secure circuitry.
4) No secure personality in the radio codeplug.
With KVL attached to radio
and radio on, verify display
message “KEYLOADING”
Correct
Equipment?
Activity?
Keyloading
Message”
displayed?
With KVL attached to the radio
and radio on, initiate a keyload
from the KVL and look for activity
on keyload signal at the P1000_4
connector on the GCAI Flex.
Obtain correct KVL
and cable
Yes
Yes
No
Yes
Verify GCAI data path.
Check the following
signals: GPIO4, One Wire
Repair connector using
programming failure
flowchart for details.
No
No
Inspect GCAI
flex to board
connections and
Replace GCAI
Flex if
necessary
With KVL attached to the radio
and radio on, initiate a keyload
from the keyloader and look
for activity on keyload signal at
P1000_21 on Front Kit Flex.
Activity?
Replace Front Kit
Flex
Check signal at
Front Kit connector on
the keypad P2000_21
Yes
Activity?
Yes
Check and repair Front Kit flex
connector to Keypad board
connector
No
Check signal at
R2005 on keypad board
Activity?
Check and repair
keypad to main board
connection from
P1000_21 to
J2031_21
No
Check signal at
main board connector
J2031_28
Activity?
Inspect
U4003.
Measure
power pin5?
No
V = ~5.0V?
No
Proceed to
DC Flow
chart
Inspect U4003
with keyloader
attached.
Measure mux
select pin6.
V = ~0V
Inspect Q4001 with
keyloader attached .
Measure BJT input pin2.
No
Yes
Replace U4003
V = ~1.8V
No
Yes
Replace main
Board
Replace Q4001
Yes
Initiate a keyload
and check for
activity at R2501 of
Keypad
Yes
Activity?
No
Check and repair
keypad to main board
connection from
P2001_22 to
J2301_22
Replace Keypad
Board
Yes
No
Yes
