Motorola APX 2000 Detailed Service Manual

Troubleshooting Tables: List of Board and IC Signals 7-29
GND P2000-70
Table 7-12. Main Back kit flex connector to keypad board connector Interface Pin-Out
Test Place
Backkit_Flex
Test
Place
Backkit_Flex
Signal Name Pin # Signal Name Pin #
GND P1000-1 GND P1001-1
F_DISP_RW P1000-2 GND P1001-2
PTT P1000-3 VBUS1 P1001-3
F_DISP_DATA_0 P1000-4 SSI_MACE_TX_DI
N
P1001-4
SIDE_1 P1000-5 BT_AVR_RESET P1001-5
F_DISP_DATA_1 P1000-6 SSI_RED_RX_MAC
E
P1001-6
SIDE_2 P1000-7 GND P1001-7
F_DISP_DATA_2 P1000-8 HIGH_SECURE_D
ATA_MACE
P1001-8
MONITOR P1000-9 GPS_BT_32KHZ P1001-9
F_DISP_DATA_3 P1000-10 SECURE_HIGH_N
ORM
P1001-10
GND P1000-11 GND P1001-11
F_DISP_DATA_4 P1000-12 SSI_BLACK_TX_M
ACE
P1001-12
GPIO_3_RTS_FILLSENSE P1000-13 BT_PTT P1001-13
F_DISP_DATA_5 P1000-14 SSI_BLACK_RX P1001-14
GPIO_2_DM_RXDC_FILL
DATA
P1000-15 BT_SPARE_1.8 P1001-15
F_DISP_DATA_6 P1000-16 GND P1001-16
GPIO_1_DP_TXDC_FILLR
EQ
P1000-17 ACC_SPKR_UNMU
TE
P1001-17
F_DISP_DATA_7 P1000-18 SSI_OPT_CLK P1001-18
GCAI_1WIRE_5V P1000-19 AVR_STATUS_1.8V P1001-19
GND P1000-20 GND P1001-20
Table 7-11. Main Back kit flex connector to main board connector Interface Pin-Out (Continued)
Test
Place
Backkit_Flex
Test
Place
Backkit_Flex
Signal Name Pin # Signal Name Pin #

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
