Motorola APX 2000 Detailed Service Manual

Troubleshooting Tables: List of Board and IC Signals 7-27
GND P2000-11 GND P2001-11
F_DISP_DATA_4 P2000-12 SSI_BLACK_TX_MAC
E
P2001-12
GPIO_3_RTS_FILLSENSE P2000-13 BT_PTT P2001-13
F_DISP_DATA_5 P2000-14 SSI_BLACK_RX P2001-14
GPIO_2_DM_RXDC_FILLDATA P2000-15 BT_SPARE_1.8 P2001-15
F_DISP_DATA_6 P2000-16 GND P2001-16
GPIO_1_DP_TXDC_FILLREQ P2000-17 ACC_SPKR_UNMUTE P2001-17
F_DISP_DATA_7 P2000-18 SSI_OPT_CLK P2001-18
GCAI_1WIRE_5V P2000-19 AVR_STATUS_1.8V P2001-19
GND P2000-20 GND P2001-20
GPIO_4_CTS_KEYFAIL_FILLCLK P2000-21 USB_BOOT_1.8V P2001-21
F_DISP_RW_EN P2000-22 V_EXT_1.85 P2001-22
VBUS2 P2000-23 V_SW_3.60 P2001-23
GND P2000-24 VRTC P2001-24
VBUS2 P2000-25 BT_HOST_WAKEUP_1
.8V
P2001-25
F_DISP_DATA_CMD P2000-26 V_SAFE P2001-26
GPIO_0 P2000-27 BT_WAKEUP_1.8V P2001-27
V_2.775D P2000-28 KEYFAIL P2001-28
Ext_MIC_Neg_DP P2000-29 BT_SHUTDOWN P2001-29
GND P2000-30 OPT_SSI_SYNC P2001-30
Ext_Mic_Pos_DP P2000-31 BT_UART_TX_1.8V P2001-31
MAIN_DISPLAY_LED1 P2000-32 MACE_WAKEUP P2001-32
Ext_SPKR_Neg_DP P2000-33 BT_UART_RX_1.8V P2001-33
MAIN_DISPLAY_LED2 P2000-34 MACE_RESET P2001-34
Ext_SPKR_Pos_DP P2000-35 BT_UART_RTS_1.8V P2001-35
MAIN_DISPLAY_LED3 P2000-36 OMAP_RESET P2001-36
GND P2000-37 BT_UART_CTS_1.8V P2001-37
MAIN_DISPLAY_LED4 P2000-38 TX_INHIBIT P2001-38
SPKR+ P2000-39 GND P2001-39
Table 7-11. Main Back kit flex connector to main board connector Interface Pin-Out (Continued)
Test
Place
Backkit_Flex
Test
Place
Backkit_Flex
Signal Name Pin # Signal Name Pin #

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
