Motorola APX 2000 Detailed Service Manual

Troubleshooting Tables: List of Board and IC Signals 7-31
FREQ_SEL_2 P1000-48 V_SW_5 P1001-48
MIC- P1000-49 KP_COL_1 P1001-49
FREQ_SEL_3 P1000-50 KP_ROW_0 P1001-50
GND P1000-51 KP_COL_2 P1001-51
GND P1000-52 KP_ROW_1 P1001-52
SPEAKER_RED_1 P1000-53 KP_COL_3 P1001-53
GND P1000-54 KP_ROW_2 P1001-54
SPEAKER_GREEN_1 P1000-55 KP_COL_4 P1001-55
GND P1000-56 KP_ROW_3 P1001-56
SPEAKER_AMBER_1 P1000-57 KEYPAD_WHITE_L
ED
P1001-57
TX_RX_LED_AMBER P1000-58 KP_ROW_4 P1001-58
SW_5+ P1000-59 GND P1001-59
TX_RX_LED_RED P1000-60 GND P1001-60
GND P1000-61
TX_RX_LED_GREEN P1000-62
GND P1000-63
GND P1000-64
EMERG_BTN P1000-65
ON_OFF_SWITCH P1000-66
GND P1000-67
VOLUME P1000-68
GND P1000-69
GND P1000-70
Table 7-12. Main Back kit flex connector to keypad board connector Interface Pin-Out (Continued)
Test Place
Backkit_Flex
Test
Place
Backkit_Flex
Signal Name Pin # Signal Name Pin #

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
