Motorola APX 2000 Detailed Service Manual

7-36 Troubleshooting Tables: List of Board and IC Signals
C2009 VBUS2 P2000-23
chassis GND P2000-24
None VBUS2 P2000-25
None F-DISP_DATA_CMD P2000-26
R2004 GPIO_0 P2000-27
None V_2.755D P2000-28
E14 EXT_MIC_NEG_DP P2000-29
None OMAP_RESET_OUT P2000-30
C16 EXT_MIC_POS_DP P2000-31
None MAIN_DISPLAY_LED1 P2000-32
R2013 EXT_SPKR_POS_DP P2000-33
None MAIN_DISPLAY_LED2 P2000-34
R2014 EXT_SPKR_NEG_DP P2000-35
None MAIN_DISPLAY_LED3 P2000-36
chassis GND P2000-37
None MAIN_DISPLAY_LED4 P2000-38
C2 SPKR+ P2000-39
None F_DISP_BD_ID P2000-40
None SPKR+ P2000-41
chassis GND P2000-42
C4 SPKR- P2000-43
C6 FREQ_SEL_0 P2000-44
None SPKR- P2000-45
C7 FREQ_SEL_1 P2000-46
D5 MIC+ P2000-47
C9 FREQ_SEL_2 P2000-48
D7 MIC- P2000-49
C32 FREQ_SEL_3 P2000-50
chassis GND P2000-51
None VCC_1.85 P2000-52
Table 7-14. Keypad board connector to front kit flex Interface Pin-Out (Continued)
Test Place
KeyBoard
Signal Name Pin #

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
