8-102 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: VHF (84012320001 / PC000352A01)
R6304M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6306M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6310M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6311M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6312M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6313M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6314M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6316M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6401M6 0613952R18 RES,MF,51KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6402M6 0613952R32 RES,MF,200KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6403M6 0613952Q81 RES,MF,2200,5,.0625,SM,0
402,200,PB-FREE
R6404M6 0613952Q81 RES,MF,2200,5,.0625,SM,0
402,200,PB-FREE
R6405M6 0613952Q75 RES,MF,1.2KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6406M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6407M6 0613952Q81 RES,MF,2200,5,.0625,SM,0
402,200,PB-FREE
R6409M6 0613952N01 CER CHIP RES 10.0K OHM
1 0402
Ref. Des. Part Number Description
R6410M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6411M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6414M6 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6415M6 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6416M6 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6417M6 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6419M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6420M6 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
R6421M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6422M6 0613952Q51 RES,MF,120,5,.0625,SM,04
02,200,PB-FREE
R6423M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6424M6 0613952N01 CER CHIP RES 10.0K OHM
1 0402
R6425M6 0613952Q80 RES,MF,2KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6426M6 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R6427M6 0613952R11 RES,MF,27KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6428M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6429M6 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
Ref. Des. Part Number Description
R6430M6 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R6431M6 0613952Q81 RES,MF,2200,5,.0625,SM,0
402,200,PB-FREE
R6432M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6433M6 0613952Q32 RES,MF,20OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6434M6 0613952Q32 RES,MF,20OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6435M6 0613952N01 CER CHIP RES 10.0K OHM
1 0402
R6436M6 NOTPLACED 64AM DUMMY PART NUM-
BER
R6492M6 0613952Q79 RES,MF,1800,5,.0625,SM,0
402,200,PB-FREE
R6501M6 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R6502M6 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R6503M6 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R6504M6 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R6505M6 0613952Q80 RES,MF,2KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6506M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6507M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6508M6 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
R6509M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6510M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
R6511M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6512M6 0613952N01 CER CHIP RES 10.0K OHM
1 0402
R6513M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6514M6 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R6515M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6516M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6517M6 0613952Q63 RES,MF,390OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6518M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6519M6 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R6520M6 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6521M6 0615049H01 RES,MF,.2OHM,1%,.5W,120
6,KAMAYA 0.2 OHM CHIP
RES
R6522M6 0613952M66 CER CHIP RES 4750 OHM
1% 0402
R6523M6 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R6524M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6525M6 NOTPLACED 64AM DUMMY PART NUM-
BER
R6526M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6527M6 0613952N87 RES,MF,78.7KOHM,1%,.06
25W,SM,0402,200PPM/
CEL,PB-FREE
R6528M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
