8-104 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: VHF (84012320001 / PC000352A01)
R705M7 0613952Q75 RES,MF,1.2KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R706M7 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R707M7 0613952Q67 RES,MF,560OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R708M7 0613952Q45 RES,MF,68OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R709M7 NOTPLACED 64AM DUMMY PART NUM-
BER
R721M7 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R722M7 0613952Q56 RES,MF,200OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R723M7 0613952Q82 RES,MF,2.4KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R728M7 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R729M7 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R730M7 0613952Q84 RES,MF,3KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R734M7 0613952Q47 RES,MF,82OHM,5%,.0625
W,SMD,0402,200PPM/
CEL,CER CHIP 82.0 OHM
5%
R736M7 0613952Q55 RES,MF,180OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R741M7 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R742M7 0613952R23 RES,MF,82KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R743M7 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
Ref. Des. Part Number Description
R744M7 0613952Q91 RES,MF,5600,5,.0625,SM,0
402,200,PB-FREE
R745M7 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R746M7 0613952Q34 RES,MF,24OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R747M7 0613952Q39 RES,MF,39OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R748M7 0613952Q47 RES,MF,82OHM,5%,.0625
W,SMD,0402,200PPM/
CEL,CER CHIP 82.0 OHM
5%
R751M7 0613952Q59 RES,MF,270OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R754M7 0613952Q71 RES,MF,820OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R757M7 0613952Q59 RES,MF,270OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R761M7 0613952Q23 RES,MF,8.2OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R762M7 0613952R08 RES,MF,20KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R763M7 0613952R19 RES,MF,56KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R765M7 2414017P23 IDCTR,CHIP,68NH,5%,180
MA,2.2OHM,CER,8
Q,800MHZ SRF,SM,0402,P
R766M7 0613952Q92 RES,MF,6.2KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R769M7 0613952Q29 RES,MF,15OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R771M7 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
Ref. Des. Part Number Description
R776M7 0613952Q67 RES,MF,560OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R778M7 2113944A30 CAP,CHIP,27PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
R779M7 NOTPLACED 64AM DUMMY PART NUM-
BER
R785M7 0613952Q60 RES,MF,300OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R799M7 0613952Q60 RES,MF,300OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R809M7 0613952Q31 RES,MF,18OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R822M7 NOTPLACED 64AM DUMMY PART NUM-
BER
R823M7 NOTPLACED 64AM DUMMY PART NUM-
BER
R901M16 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R902M16 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R903M16 0613952R21 RES,MF,68KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R904M16 0613952R13 RES,MF,33KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R905M16 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R906M16 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R907M16 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
Ref. Des. Part Number Description
R908M16 2113944A30 CAP,CHIP,27PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
R909M16 2414017P21 IDCTR,CHIP,47NH,5%,200
MA,2OHM,CER,8
Q,700MHZ
SRF,SM,0402,PB-
T506M21 2575851B01 XFMR,BALUN,RF XFMR
BALUN
T507M21 2575851B02 XFMR,BALUN,25,SM,RF
XFMR BALUN
U1101M11 5188032U43 IC,SENSING CIR-
CUIT,INA138,SM,SOT-23/
5,1PER PKG
U1103M11 5185070Y01 IC,TEMP SENS
U1104M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1105M11 5180390L83 IC,CNTLR,SM,1PER PKG
U1106M11 5175772B05 IC,LTC5532ES6,SOT-
23,1PER PKG,PRCN RF
DET
U1112M11 5175772B04 IC,HMC468LP3E,QFN,1 DB
LSB GAAS MMIC ATTEN
U1113M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1114M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1119M11 5109522E94 GATE,AND,1PER
PKG,SM,2 INPUT IN NANO
PKG
U1121M11 5114000B52 IC,XOR,LOGIC LEVEL
SHIFTER,1PER
PKG,SM,SOT-353,PB-FREE
U1125M11 5175206H01 IC,DAC,W/ 5 PPM/C INT
REF
U1126M11 5109817F77 IC,COMPTR,LMV7275,SC7
0-5
U1127M11 5171779H01 IC,ANLG SW,SC70,SC70-
6,1PER PKG,SPDT ANLG
SW
Ref. Des. Part Number Description
