8-178 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF1 (84012313002 / PC000353A01)
R2136M2 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2137M2 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2138M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2139M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2142M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2144M2 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2145M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2146M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2147M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2148M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2149M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2151M2 NOTPLACED 64AM DUMMY PART NUM-
BER
R2153M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2154M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2192M2 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R2197M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2198M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2199M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2200M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2202M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2204M2 0613952Q85 RES,MF,3.3KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2206M2 0613952Q85 RES,MF,3.3KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2207M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2235M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2244M2 0613952Q72 RES,MF,910OHM,5%,.0625
W,SM,0402,PB-FREE
R2245M2 0613952Q63 RES,MF,390OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2246M2 0613952Q60 RES,MF,300OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2254M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2255M2 0613952R32 RES,MF,200KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2601M13 NOTPLACED 64AM DUMMY PART NUM-
BER
R2602M13 0613952H47 RES,MF,82OHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
R2603M13 0613952H47 RES,MF,82OHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
Ref. Des. Part Number Description
R2604M13 0613952H47 RES,MF,82OHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
R2605M13 0613952G67 RES,MF,0,1,.1,SM,0603,PB-
FREE
R2606M13 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2803M1 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2804M1 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R2805M1 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R2806M1 0613952Q59 RES,MF,270OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2807M1 0613952Q56 RES,MF,200OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2808M1 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R2810M1 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2811M1 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R2812M1 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2813M1 NOTPLACED 64AM DUMMY PART NUM-
BER
R2817M1 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3103M22 0613952Q31 RES,MF,18OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3105M22 0613952Q60 RES,MF,300OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R3106M22 0613952Q60 RES,MF,300OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3107M22 0613952Q60 RES,MF,300OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3108M22 0613952Q31 RES,MF,18OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3109M22 0613952Q60 RES,MF,300OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3114M22 0613952R11 RES,MF,27KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3118M22 0613952R07 RES,MF,18KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3127M22 0613952Q47 RES,MF,82OHM,5%,.0625
W,SMD,0402,200PPM/
CEL,CER CHIP 82.0 OHM
5%
R3146M22 0613952Q95 RES,MF,8.2KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R3149M22 0613952Q93 RES,MF,6.8KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R3158M22 0613952Q53 RES,MF,150OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3159M22 0613952Q45 RES,MF,68OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3160M22 0613952Q53 RES,MF,150OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4005M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4006M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4007M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
