Motorola APX 2000 Detailed Service Manual

8-224 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2 (84012432001 / PC000354A01)
UHF2 Transceiver (RF) Board Parts List –
84012432001
Ref. Des. Part Number Description
C101M12 2113944A40 CAP CER CHP 100.0PF
50V 5%
C1101M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1102M11 21012118001 CAP,FXD,1UF,10%,25V-
DC,X7R,0805,LEAD-FREE/
ROHS COMPLIANT
C1103M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1104M11 NOTPLACED 64AM DUMMY PART NUM-
BER
C1105M11 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
C1106M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1107M11 2113944A40 CAP CER CHP 100.0PF
50V 5%
C1108M11 2113946B02 CAP CER CHP 0.047UF
10V 10,
C1110M11 2113944A40 CAP CER CHP 100.0PF
50V 5%
C1111M11 211394 5Y02 CAP,FXD, .1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1112M11 2113945B01 CAP CER CHP 6800PF 25V
10%
C1113M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1116M11 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1117M11 2113945A12 CAP CER CHP 3300PF 50V
10%
C1118M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1119M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1120M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1122M11 2113944M04 CAP,FXD,2.7PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1123M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1124M11 2113945A13 CAP CER CHP 4700PF 50V
10%
C1125M11 2113944A23 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C1126M11 2113945A09 CAP CER CHP 1000PF 50V
10%
C1127M11 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1128M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1129M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1130M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1135M11 NOTPLACED 64AM DUMMY PART NUM-
BER
C1137M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1138M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1139M11 2113944A25 CAP CER CHP 10.0PF 50V
+/- 0.5PF
C1140M11 2113945A13 CAP CER CHP 4700PF 50V
10%
C1141M11 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1142M11 2113945A09 CAP CER CHP 1000PF 50V
10%
C1155M11 NOTPLACED 64AM DUMMY PART NUM-
BER
Ref. Des. Part Number Description
C1160M11 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C1161M11 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C1165M11 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1301M3 21012119001 CAP,FXD,2.2UF,20%,6.3V-
DC,-55DEG CMIN,85DEG
CM,X5R,0402
C1302M3 2113944A21 CAP CER CHP 6.8PF 50V
+/- 0.5PF
C1303M3 2113956A51 CAP,FXD,1UF,+10%,-
10%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX,P
C1304M3 2113944A26 CAP CER CHP 12.0PF 50V
5%
C1305M3 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1306M3 2187893N01 CAP 1UF, 6.3V, X5R, 0402
PACKAGE
C1307M3 2113944A26 CAP CER CHP 12.0PF 50V
5%
C1308M3 2113945A09 CAP CER CHP 1000PF 50V
10%
C1309M3 2113944A26 CAP CER CHP 12.0PF 50V
5%
C1310M3 2187893N01 CAP 1UF, 6.3V, X5R, 0402
PACKAGE
C1311M3 2113956A51 CAP,FXD,1UF,+10%,-
10%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX,P
C1312M3 2113956A51 CAP,FXD,1UF,+10%,-
10%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX,P
C1313M3 2187893N01 CAP 1UF, 6.3V, X5R, 0402
PACKAGE
Ref. Des. Part Number Description
C1314M3 2113944M20 CAP,FXD,12PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1315M3 2175389H01 CAP,.5PF, CHIP, 0402,
CERAMIC, 50 V
C1317M3 2188881Y12 CAPACITOR CERAMIC
NPO HIGH FREQUENCY
16 VOLT (REPLACES
2104801Z12)
C1318M3 2113944A13 CAP CER CHP 3.3PF 50V
+/- 0.25PF
C1319M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1320M3 2113944A28 CAP CER CHP 18.0PF 50V
5%
C1321M3 2113944A29 CAP CER CHP 22.0PF 50V
5%
C1322M3 2113944A29 CAP CER CHP 22.0PF 50V
5%
C1323M3 2113944A29 CAP CER CHP 22.0PF 50V
5%
C1324M3 2115153H03 CAP, CERAMIC, COG
C1325M3 2113944A29 CAP CER CHP 22.0PF 50V
5%
C1326M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1327M3 2113944A28 CAP CER CHP 18.0PF 50V
5%
C1328M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1329M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1330M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
Ref. Des. Part Number Description
