Motorola APX 2000 Detailed Service Manual

8-262 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2 (84012432001 / PC000354A01)
U6302M6 5102495J13 IC,MICROP,P1710ZZGE,BG
A,12MHZ,32BITS
U6304M6 0105955U25 ASSY,ASSY,ASSY,IC,BGA
SPEC PROG, FLSH MEM
U6401M6 5175772B38 IC,IC ANLG TEMP SENSOR
U6402M6 5115453H01 IC,OP AMP,2PER PKG,RAIL
TO RAIL OUTPUT, 8 PIN
BGA
U6404M6 5175772B38 IC,IC ANLG TEMP SENSOR
U6405M6 5188348V06 IC,AUDIO
CODEC,SM,AUDIO CODEC
U6408M6 5188521T01 IC,VREF,SM,SOT23,1PER
PKG,.5%,1.25 TO
13.75,PRCN BANDGAP
ADJUS
U6409M6 51009000001 IC,COMPTR,SC70,NANOP-
OWER, 1.8V, SC70
COMPTR
U6410M6 5175772B38 IC,IC ANLG TEMP SENSOR
U6411M6 5109731C55 IC,AU AMP,BGA,2.75 FXD
GAIN MONO FLTR-FREE
U6501M6 5185143E77 IC,CUST,BGA,IC, MAKO
ASIC, CMOS PWR MGMT
U6502M6 4871987H01 XSTR,BIP GP
POWER,12V,1A,LOW
FREQ XSTR
U6503M6 5171674H01 IC,OP AMP,SO-8,OP AMP
U6504M6 5171682H01 IC,DC TO DC CON-
VERTER,800MA BUCK
REGLTR
U6505M6 5189631P01 IC,0PER PKG,SYNC STEP-
DOWN CONV
U6506M6 5184790Y04 IC,LINEAR VOLTAGE REG-
ULATOR,400MA
U6507M6 5171682H01 IC,DC TO DC CON-
VERTER,800MA BUCK
REGLTR
U6508M6 51009366001 IC,LNR V
REGLTR,LLP6,500MA LOW
DROPOUT CMOS LINEAR
REG
U6509M6 5175114H01 IC,SNGL AND GATE
MICROPAK
Ref. Des. Part Number Description
U6510M6 5114007A47 IC,OR,17SZ32,1PER
PKG,SOT-353,PB FREE
U6511M6 5171339H01 IC,MC78LC18,MICROPO-
WER V REGLTR
U6601M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U702M7 5164015H28 IC,CUST,MULTI PROTO-
COL/BAND TRANSCVR
IC,SM,BGA,TRIDENT,
INTEG
U738M7 5171972L01 IC,SW,SP3T RF SW
U746M7 4805218N63 XSTR,GEN PURPOSE
SMALL SIG,SOT-
323,BROADBAND AND
XSTR
VR101M12 4813977M29 DIODE,ZEN,MBZ5250,SM,S
OT-23,ZEN,PB-FREE
VR1905M20 4815096H01 DIODE,VCTR,10V,1SV305G
,VCTR DIODE 1SV305
VR1906M20 4815096H01 DIODE,VCTR,10V,1SV305G
,VCTR DIODE 1SV305
VR1907M20 4815096H01 DIODE,VCTR,10V,1SV305G
,VCTR DIODE 1SV305
VR1908M20 4815096H01 DIODE,VCTR,10V,1SV305G
,VCTR DIODE 1SV305
VR200M12 4813977M29 DIODE,ZEN,MBZ5250,SM,S
OT-23,ZEN,PB-FREE
VR601M19 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
VR602M19 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
Y1304M3 48014600001 OSC,TCXO,26.0
Y6501M6 93012044001 OSC,XO,24.576MHZ,SM,XT
AL U SMD 5.0X3.2
24.576MHZ
Y6502M6 4809995L05 RESON,QRTZ,32.768KHZ,
SM,FUND,9PF LOAD CAP,-
40DEG C MIN,85DE
Ref. Des. Part Number Description
Y6601M6 4802582S85 RESON,QRTZ,12MHZ,10P
PM TOL,18PPM
STAB,SM,FUND,AT,10PF
LOAD CAP
Y701M7 4871886H01 OSC,VO,16.8 MHZ VCTXO
.8PPM
Ref. Des. Part Number Description
