Motorola APX 2000 Detailed Service Manual

8-338 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 700 – 800 MHz (84012266001 / PC000351A01)
U4003M2 5188691V01 IC,MUX/
DEMUX,NC7SB3157P6X,S
M,SC70-6,1PER
PKG,BUS,PB FREE
U4004M2 5116783H01 IC,ANLG
SW,SN74LVC2G66YZPR,S
M,2PER
PKG,0CHANNELS,BILAT-
ERAL,DL
U402M20 5180428L15 SW,RF
SWITCH,SPDT,SMT,6W,3V
U403M20 5180428L15 SW,RF
SWITCH,SPDT,SMT,6W,3V
U404M20 5180428L15 SW,RF
SWITCH,SPDT,SMT,6W,3V
U405M20 5180428L15 SW,RF
SWITCH,SPDT,SMT,6W,3V
U406M20 4885316E32 XSTR,BIP RF SML
SGNL,SLCN,BFR380F,SM,
SMT,6V,380W,80A,14MHZ,T
R
U407M20 4885316E32 XSTR,BIP RF SML
SGNL,SLCN,BFR380F,SM,
SMT,6V,380W,80A,14MHZ,T
R
U408M20 5103535B53 IC,INVTR,DL,NC7WZ04L6X
,2PER PKG,SC70
U507M21 5164015H81 IC,MXR,SM
U601M19 5102495J14 IC,IF,IF DIGITILIZING SUB-
SYSTEM IC,AD9864,QFN
U602M19 4885316E32 XSTR,BIP RF SML
SGNL,SLCN,BFR380F,SM,
SMT,6V,380W,80A,14MHZ,T
R
U603M19 5109522E84 IC,DL SCHT TRIG MICRO
PAK
U604M19 5109522E84 IC,DL SCHT TRIG MICRO
PAK
U605M19 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
Ref. Des. Part Number Description
U606M19 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U607M19 5186311J24 IC,BFR,1PER
PKG,NC7SZ125,ACTIVE
HIGH,BFR,3ST,SM,5.5
U6101M6 0180706J18 IC,PGM,PGM CPLD
U6102M6 5188691V01 IC,MUX/
DEMUX,NC7SB3157P6X,S
M,SC70-6,1PER
PKG,BUS,PB FREE
U6103M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U6104M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U6105M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U6201M6 5185941F26 IC,COMPTR,LMV7219,SM,
SOT-23/5,IC,LM7219,COM-
PARATOR,NOPB
U6301M6 51012058002 IC,SDRAM,512MBITS,8
MEG X 16 X 4
BANKS,6NS,SM,MOBILE
LPDDR 5
U6302M6 5102495J13 IC,MICROP,P1710ZZGE,BG
A,12MHZ,32BITS
U6304M6 0105955U25 ASSY,ASSY,ASSY,IC,BGA
SPEC PROG, FLSH MEM
U6401M6 5175772B38 IC,IC ANLG TEMP SENSOR
U6402M6 5115453H01 IC,OP AMP,2PER PKG,RAIL
TO RAIL OUTPUT, 8 PIN
BGA
U6404M6 5175772B38 IC,IC ANLG TEMP SENSOR
U6405M6 5188348V06 IC,AUDIO
CODEC,SM,AUDIO CODEC
U6408M6 5188521T01 IC,VREF,SM,SOT23,1PER
PKG,.5%,1.25 TO
13.75,PRCN BANDGAP
ADJUS
U6409M6 51009000001 IC,COMPTR,SC70,NANOP-
OWER, 1.8V, SC70
COMPTR
Ref. Des. Part Number Description
U6410M6 5175772B38 IC,IC ANLG TEMP SENSOR
U6411M6 5109731C55 IC,AU AMP,BGA,2.75 FXD
GAIN MONO FLTR-FREE
U6501M6 5185143E77 IC,CUST,BGA,IC, MAKO
ASIC, CMOS PWR MGMT
U6502M6 4871987H01 XSTR,BIP GP
POWER,12V,1A,LOW
FREQ XSTR
U6503M6 5171674H01 IC,OP AMP,SO-8,OP AMP
U6504M6 5171682H01 IC,DC TO DC CON-
VERTER,800MA BUCK
REGLTR
U6505M6 5189631P01 IC,0PER PKG,SYNC STEP-
DOWN CONV
U6506M6 5184790Y04 IC,LINEAR VOLTAGE REG-
ULATOR,400MA
U6507M6 5171682H01 IC,DC TO DC CON-
VERTER,800MA BUCK
REGLTR
U6508M6 51009366001 IC,LNR V
REGLTR,LLP6,500MA LOW
DROPOUT CMOS LINEAR
REG
U6509M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U6510M6 5114007A47 IC,OR,17SZ32,1PER
PKG,SOT-353,PB FREE
U6511M6 5171339H01 IC,MC78LC18,MICROPO-
WER V REGLTR
U6601M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U702M7 5164015H28 IC,CUST,MULTI PROTO-
COL/BAND TRANSCVR
IC,SM,BGA,TRIDENT,
INTEG
U738M7 5171972L01 IC,SW,SP3T RF SW
U739M7 5103535B53 IC,INVTR,DL,NC7WZ04L6X
,2PER PKG,SC70
U746M7 4805218N63 XSTR,GEN PURPOSE
SMALL SIG,SOT-
323,BROADBAND AND
XSTR
Ref. Des. Part Number Description
VR101M12 4813977M29 DIODE,ZEN,MBZ5250,SM,S
OT-23,ZEN,PB-FREE
VR200M12 4813977M29 DIODE,ZEN,MBZ5250,SM,S
OT-23,ZEN,PB-FREE
VR3010M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
VR3011M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
VR3048M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
VR601M19 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
VR602M19 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79,SOD-523/SC-79
Y1304M3 48014600001 OSC,TCXO,26.0
Y3020M22 48012102005 RESON,NON-
QUARTZ,1025MHZ,SM,RE
SON CER 1025MHZ
Y3021M22 48012102005 RESON,NON-
QUARTZ,1025MHZ,SM,RE
SON CER 1025MHZ
Y3053M22 48012102006 RESON,NON-
QUARTZ,1110MHZ,SM,RES
ON CER 1110MHZ
Y6501M6 93012044001 OSC,XO,24.576MHZ,SM,XT
AL U SMD 5.0X3.2
24.576MHZ
Y6502M6 4809995L05 RESON,QRTZ,32.768KHZ,
SM,FUND,9PF LOAD CAP,-
40DEG C MIN,85DE
Y6601M6 4802582S85 RESON,QRTZ,12MHZ,10P
PM TOL,18PPM
STAB,SM,FUND,AT,10PF
LOAD CAP
Y701M7 4871886H01 OSC,VO,16.8 MHZ VCTXO
.8PPM
Ref. Des. Part Number Description

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
