Motorola APX 2000 Detailed Service Manual

8-368 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 900 MHz (84012478001)
C2127M2 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C2128M2 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C2129M2 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C212M12 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C2130M2 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C213M12 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C214M12 2113944A31 CAP CER CHP 33.0PF 50V
5%
C215M12 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C216M12 2113944A31 CAP CER CHP 33.0PF 50V
5%
C217M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C2201M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2202M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2203M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2211M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2212M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2213M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2214M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2215M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2216M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
Ref. Des. Part Number Description
C2221M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2222M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2223M2 2113944A40 CAP CER CHP 100.0PF
50V 5%
C2301M13 2113944C37 CAP CER CHP 39.0PF 50V
5%
C2302M13 2113944M22 CAP,FXD,15PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C2303M13 2113944A36 CAP CER CHP 68.0PF 50V
5%
C2304M13 2113944C36 CAP CER CHP 33.0PF 50V
5%
C2305M13 2115153H47 CAP, CERAMIC, COG
C2306M13 2115153H47 CAP, CERAMIC, COG
C2307M13 2113944C16 CAP CER CHP 2.7PF 50V
+/- 0.25PF
C2308M13 2113944C18 CAP CER CHP 3.3PF 50V
+/- 0.25PF
C2309M13 2113946K02 CAP CER CHP 0.10UF 16V
C2401M2 NOTPLACED 64AM DUMMY PART
NUMBER
C2402M2 NOTPLACED 64AM DUMMY PART
NUMBER
C2403M2 NOTPLACED 64AM DUMMY PART
NUMBER
C2404M2 NOTPLACED 64AM DUMMY PART
NUMBER
C2806M1 NOTPLACED 64AM DUMMY PART
NUMBER
C3005M22 2113944A32 CAP CER CHP 39.0PF 50V
5%
C3006M22 2113944A32 CAP CER CHP 39.0PF 50V
5%
C3010M22 2113944A31 CAP CER CHP 33.0PF 50V
5%
C3012M22 2113946K02 CAP CER CHP 0.10UF 16V
C3014M22 2115153H11 CAP, CERAMIC, COG
Ref. Des. Part Number Description
C3015M22 2115153H11 CAP, CERAMIC, COG
C3022M22 2115153H11 CAP, CERAMIC, COG
C3023M22 2115153H12 CAP, CERAMIC, COG
C3026M22 2115153H15 CAP, CERAMIC, COG
C3027M22 2115153H15 CAP, CERAMIC, COG
C3042M22 2113944A32 CAP CER CHP 39.0PF 50V
5%
C3046M22 2113944A31 CAP CER CHP 33.0PF 50V
5%
C3049M22 2113946K02 CAP CER CHP 0.10UF 16V
C3050M22 2113944M04 CAP,FXD,2.7PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3051M22 2113944M03 CAP,FXD,2.4PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3054M22 2115153H08 CAP, CERAMIC, COG
C3055M22 2115153H12 CAP, CERAMIC, COG
C3056M22 2115153H16 CAP, CERAMIC, COG
C3057M22 2115153H09 CAP, CERAMIC, COG
C3065M22 2113944A31 CAP CER CHP 33.0PF 50V
5%
C3067M22 2113946B04 CAP CER CHP 0.10UF 10V
10%
C3068M22 2113944A32 CAP CER CHP 39.0PF 50V
5%
C3069M22 2115153H33 CAP, CERAMIC, COG
C4005M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C4006M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C4007M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C413M20 2115153H47 CAP, CERAMIC, COG
C421M20 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C422M20 2113944A31 CAP CER CHP 33.0PF 50V
5%
Ref. Des. Part Number Description
C423M20 2115153H44 CAP, CERAMIC, COG
C424M20 2113944A31 CAP CER CHP 33.0PF 50V
5%
C425M20 2115153H29 CAP, CERAMIC, COG
C426M20 2113944A63 CAP,FXD,1PF,.25PF+/-,50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX,P
C427M20 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C428M20 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C429M20 2113944A31 CAP CER CHP 33.0PF 50V
5%
C430M20 2115153H44 CAP, CERAMIC, COG
C431M20 2113944A31 CAP CER CHP 33.0PF 50V
5%
C432M20 2115153H25 CAP, CERAMIC, COG
C433M20 2113944A63 CAP,FXD,1PF,.25PF+/-,50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX,P
C434M20 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C451M20 2115153H47 CAP, CERAMIC, COG
C453M20 2115153H47 CAP, CERAMIC, COG
C455M20 2115153H47 CAP, CERAMIC, COG
C484M20 2115153H03 CAP, CERAMIC, COG
C485M20 2113944A63 CAP,FXD,1PF,.25PF+/-,50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX,P
C488M20 2113944V13 CAP,FXD,2.7PF,.1PF+/-
,50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
C490M20 2113944V07 CAP,FXD,1.5PF,.1PF+/-
,50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
C492M20 2113944V13 CAP,FXD,2.7PF,.1PF+/-
,50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
Ref. Des. Part Number Description
