Motorola APX 2000 Detailed Service Manual

8-382 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 900 MHz (84012478001)
U6409M6 51009000001 NANOPOWER, 1.8V,
SOT23 COMPARATOR
U6410M6 5175772B38 IC ANALOG
TEMPERATURE SENSOR
U6411M6 5109731C55 IC 2.75 FIXED GAIN MONO
FILTER-FREE AMPLFR
U6501M6 5185143E77 IC, MAKO ASIC, CMOS
PWR MGMT
U6502M6 4871987H01 LOW FREQUENCY
TRANSISTOR
U6503M6 5171674H01 OP AMP
U6504M6 5171682H01 800MA BUCK REGULATOR
U6505M6 5189631P01 IC,SYNC STEP-DOWN
CONV
U6506M6 5184790Y04 IC,400MA ADJ VREG
LDO,SOT23
U6507M6 5171682H01 800MA BUCK REGULATOR
U6508M6 51009366001 500MA LOW DROPOUT
CMOS LINEAR REG.
U6509M6 5175114H01 SINGLE AND GATE
MICROPAK
U6510M6 5114007A47 IC,OR,17SZ32,1PER
PKG,SOT-353,PB FREE
U6511M6 5171339H01 MICROPOWER VOLTAGE
REGULATOR
U6601M6 5175114H01 SINGLE AND GATE
MICROPAK
U702M7 5164015H28 IC,TRIDENT,INTEG
SYNTH,RX/TX BSBND
U738M7 5171972L01 SP3T RF SWITCH
U739M7 5103535B53 IC,INVTR,DL,NC7WZ04L6X
,2PER PKG,SC70
U746M7 4805218N63 RF TRANS SOT 323
BFQ67W
VR101M12 4813977M29 DIODE,VREF,MBZ5250,SM,
SOT-23,20V,.225W,ZEN
VR200M12 4813977M29 DIODE,VREF,MBZ5250,SM,
SOT-23,20V,.225W,ZEN
VR3006M22 4805656W87 DIODE,VCTR, @
15V,1SV279,,SOD-523/SC-
79
Ref. Des. Part Number Description
VR3008M22 4805656W87 DIODE,VCTR, @
15V,1SV279,,SOD-523/SC-
79
VR3009M22 4805656W87 DIODE,VCTR, @
15V,1SV279,,SOD-523/SC-
79
VR3010M22 4805656W87 DIODE,VCTR, @
15V,1SV279,,SOD-523/SC-
79
VR3011M22 4805656W87 DIODE,VCTR, @
15V,1SV279,,SOD-523/SC-
79
VR3013M22 4805656W87 DIODE,VCTR, @
15V,1SV279,,SOD-523/SC-
79
VR3014M22 4805656W87 DIODE,VCTR, @
15V,1SV279,,SOD-523/SC-
79
VR3048M22 4805656W87 DIODE,VCTR, @
15V,1SV279,,SOD-523/SC-
79
VR601M19 4805656W87 DIODE,VCTR, @
15V,1SV279,,SOD-523/SC-
79
VR602M19 4805656W87 DIODE,VCTR, @
15V,1SV279,,SOD-523/SC-
79
Y1304M3 48014600001 OSC,TCXO,26.0
Y3020M22 93012021001 RESONATOR CERAMIC
Y3053M22 48012102006 RESONATOR CERAMIC
1110MH Z
Y6501M6 93012044001 CRYSTAL UNIT SMD
5.0X3.2 24.576MHZ
Y6502M6 4809995L05 XTAL QUARTZ 32.768KHZ
CC4V-T1
Y6601M6 4802582S85 RESON,QRTZ,12MHZ,TOL
ERANCE10PPM,STABILITY
15PPM,,SM,,FUND,,LO
Y701M7 4871886H01 16.8 MHZ VCTXO .8PPM
Ref. Des. Part Number Description

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
