8-428 Schematics, Boards Overlays, and Parts Lists: Keypad Board (APX 2000/ APX 4000 (Two Knobs)) (PC000356A02 (Model 2) / PC000356A01 (Model 3))
S10 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S11 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S12 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S13 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S14 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S15 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S16 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S17 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S18 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S19 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S2 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S20 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S21 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S3 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S4 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
Ref. Des. Part Number Description
S5 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S6 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S7 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S8 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
S9 4071633L01 KYPD SW,MET
DM,18,SPST,4MA,24V,MET
DOME (FULL)
SH1 26012170001 SHIELD,CAN,STEEL,TIN
PLATED,SHIELD, MACE
SH2 26012171001 SHLD,CAN,STL,SN
PLT,SHIELD, SDRAM
U2402M3 51002923001 IC,LNR V REGLTR,3.3V
LP2989,NOPB
U2403M3 51009735001 IC,RCVR,QFN,IC, RCVR,
ONE-CHAN, QFN, LF
WAKE-UP
U2406M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2407M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2408M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2409M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2410M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2411M3 5175856M01 IC,INVTR,0MHZMAX,DL
INVTR
Ref. Des. Part Number Description
U2412M3 5114007M45 IC,NOR,1PER PKG,SOT-
353,PB-FREE
U2413M3 51007645001 IC,SDRAM,128MB,8 MEG X
16,6NS,SM,64MSRFRSH,IC,
SDRAM,128MBIT,8
U2414M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2415M3 51009372001 IC,UCNTLR,IC UCNTLR
AT32UC3A0512
U2416M3 51009669001 IC,SENSOR,SM,IC, ACCEL-
EROMETER, MOTION SEN-
SOR
U2417M3 5102836C11 IC,ANLG
SW,FSA4157,SM,SPDT,PB
FREE
U2473M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2478M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U2510M4 5185912Y05 IC,MICROPROCES-
SOR,INDIGENOUS MACE
U2525M4 5171339H01 IC,MC78LC18,MICROPO-
WER V REGLTR
U2526M4 5171988H01 IC,COMPTR,CMOS
COMPTR
VR1 NOTPLACED 64AM DUMMY PART NUM-
BER
Y2475M3 48009319001 OSC,VAR,SMD XTAL OSC
DS0211AR
Ref. Des. Part Number Description
