Motorola APX 2000 Detailed Service Manual

4-6 Troubleshooting Procedures: Power-Up Self-Check Diagnostics and Repair (Not for Field Use)
01/92 The radio should be sent to the depot for reprogramming of the security codeplug.
01/93 The radio should be sent to the depot for reflashing of the host code.
01/98 Send radio to the depot.
01/A2 The radio should be sent to the depot for reflashing of the tuning codeplug followed by
re-tuning of the radio.
02/81 The radio should be sent to the depot for examination.
02/88 Cycle power to the radio. If this does not fix the problem, then the radio should be sent
to the depot for reflashing of the DSP code.
02/90 Cycle power to the radio. If this fails to fix the problem, then the radio should be sent to
the depot for reflashing of the DSP code.
09/10 Cycle power to the radio. If this fails then follow instructions in the secure hardware
failure troubleshooting flowchart.
09/90 Cycle power to the radio. If this fails then follow instructions in the secure hardware
failure troubleshooting flowchart.
Hardware board
failed
Bluetooth error. Send radio to depot for examination.
Hardware board
failed
then
Man-Down HW error
Man-Down feature unavailable. Send radio to depot for examination.
Hardware board
mismatch
Keypad board does not support bluetooth feature. Send radio to depot.
If the Keypad board type supports “Full feature” – “Mace/GPS/BT”, updating the keypad
board firmware should resolve the error message.
Hardware board
mismatch
then
Man-Down HW error
Keypad board does not support either bluetooth or Man-down feature or both.
If the Keypad board type supports “Full feature” – “Mace/GPS/BT”, updating the keypad
board firmware should resolve the error message.
Table 4-5. Power-Up Self-Check Diagnostic Actions (Continued)
Error Code/ Error
Message
Diagnostic Actions

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
