ASTRO XTS 2500/XTS 2500I Model III 7
General Radio Operation
Status Symbols
The top two rows in the display contain symbols indicating the radio’s
status.
Table 2: Status Symbols
Symbol Indication Page
Call Received. Blinks when an Individual Call is
received.
60
View/Program Mode.
• View a list (steady).
• Program a list (blinking).
46
s
Received Signal Strength Indication (RSSI).
The received signal strength for the current site.
Trunked only. The more signal bars in the
symbol, the stronger the received signal.
77
b
Battery
• Conventional = Blinks when the battery is low.
• Smart = The number of bars (0-3) shown
indicates the charge remaining in your battery.
Blinks when battery level reaches 10% or less.
Note: Smart battery will be available at a future
date.
18
r
Talkaround.
• On = Talking directly to another radio, not
through a repeater. Conventional operation only.
• Off = Talking through a repeater.
67
C
Monitor (Carrier Squelch). The selected
channel is being monitored. Conventional
operation only.
34
T
Scan. The radio is scanning a scan list. 52
m
p
p
