Maintenance, Troubleshooting & Technical Specifications 3 - 3
e. Spray compressed air in the connector area by pointing the tube/nozzle approximately 1/2 inch (1 cm)
away from the surface.
f. Ensure that there is no lint left by the cotton tipped applicator. Remove lint if found.
g. If grease and other dirt are found on other areas of the cradle, use a lint free cloth and isopropyl alcohol to
remove.
h. Allow at least 10 to 30 minutes (depending on ambient temperature and humidity) for the isopropyl alcohol
to air dry before applying power to cradle.
CAUTION When using compressed air, always wear eye protection; do not point nozzle at yourself or
others; ensure the nozzle or tube is pointing away from your face; read warning label on
compressed air product.
NOTE If the temperature is low and humidity is high, longer drying time is required. Warm temperature
and dry humidity requires less drying time.

Motorola DS4208 Specifications

General

Connectivity	Wired
Sealing	IP43
Voltage	5 VDC ± 10%
Scan Pattern	Omnidirectional
Interface	USB, RS232, Keyboard Wedge
Decode Capability	1D
Drop Specification	Withstands multiple 6 ft. (1.8 m) drops to concrete
Operating Temperature	32° to 104° F (0° to 40° C)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 95% (non-condensing)
Lighting	Tolerant to typical artificial indoor and natural outdoor (direct sunlight) lighting conditions
Power Consumption	2.5 W (typical)
Current	500 mA
Cable Length	6 ft (1.8 m)
