Control Head E Button Configuration Screen
Control Head J Button Configuration Screen
The availability of certain button functions described below depends on your
radio model and the options you have selected for this radio. You may
therefore not be able to select some of these functions/choices for the radio
currently being configured.
For digit keys (1-9), the zero key serves as a function key. To activate a feature
programmed on a digit key, first press the zero key, then the digit key (1-9)
on which the desired feature is programmed.
MOTOROLA Radio Service Software Use UP/DOWN Arrows to Select Choice.
MCS Model: M01KHM9PW5AN
..CHANGE/VIEW:CONFIG:FEATURES:BUTTONS
CONTROL HEAD - E
[ChDn] [ChUp]
[ZnUp] ____
PWR CONTROL HEAD BUTTONS / \
[ZnDn] | CHAN |
\____/
[Unpr] [Unpr] [Unpr] [Unpr] [Unpr] [Unpr] [Unpr] [ Sel] [Menu]
MICROPHONE BUTTONS
1 [Unpr] 2 [Unpr] 3 [Unpr] UP [Unpr]
4 [Unpr] 5 [Unpr] 6 [Unpr] MIDDLE [Unpr]
7 [Unpr] 8 [Unpr] 9 [Unpr] DOWN [Unpr]
* 0 #
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP EXIT
MOTOROLA Radio Service Software Use UP/DOWN Arrows to Select Choice.
MCS Model: M01KHN9PW5AN
..CHANGE/VIEW:CONFIG:FEATURES:BUTTONS
CONTROL HEAD - J
1 2 3 [ Sel]
[ZnUp] [Unpr] [Unpr] [Unpr]
PWR CONTROL HEAD BUTTONS 4 5 6 [Menu]
[ZnDn] [Unpr] [Unpr] [Unpr]
7 8 9 [ChDn]
[Unpr] [Unpr] [Unpr]
* 0 # [ChUp]
[Unpr][Unpr][Unpr][Unpr][Unpr][Unpr][Unpr]
UP MIDDLE DOWN
MICROPHONE BUTTONS [Unpr] [Unpr] [Unpr]
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP EXIT
