100
Quik-Call II Options From the MAIN MENU, press F4, F3, F7 and then F2 to access this
screen.
From this screen, you can configure options relating to the radio’s
Quik-Call II signalling operation.
Function Key Descriptions
F5 - PRINT Prints the current system configuration.
F9 - DEFAULT Resets the fields on this screen to their default values.
Field Definitions
Tones A-B-C-D Quik-Call is a receive-only function and has four tones associated with
it (Tones A, B, C, and D). Use the UP/DOWN arrow keys to scroll
through the available Quik-Call frequencies (288.5 to 2468.2 Hz).
Quik-Call frequencies between 2468.2 Hz and 3100 Hz can be entered
directly.
Scrolling through a Quik-Call frequency will cause the corresponding
Quik-Call code to scroll as well. Tone A and Tone B should not be the
same. In some systems, it is beneficial to have Tone A = Tone C
(Common Tone A) or Tone B = Tone D (Common Tone B). These
variations are allowed. The Quik-Call frequencies and codes available
in the scroll list are shown in the Appendix under the title “Quik-Call
II Frequencies and Codes”.
Note: The frequencies you enter directly will be rounded off to
the nearest encodable frequency. Codes entered directly will be
allowed only if they are in the RSS table of code names.
Long Tone B Duration (sec) The duration of Long Tone B may be set from 0 (zero) to 34 seconds in
one-second increments.
The default is 6 seconds.
DCGB
MOTOROLA Radio Service Software Use <: keys to adjust value.
HT/JT1000/VISAR Model : Use <Enter> key to go to next feature
Serial:
CHANGE:RADIO:SIG:QUIK-CALL II
Quik-Call II Options
--------------------
Frequency Code Frequency Code
Tone A.............. 389.0 Hz 113 Tone C...............389.0 Hz 113
Tone B...............389.0 Hz 113 Tone D...............389.0 Hz 113
Long Tone B Duration (sec).......6 Auto Reset.................Enabled
Sleep Period (ms)...............60 QC Select Call LED.........Enabled
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP PRINT EXIT
