Anatomy of a
Screen
The only difference between a menu and a screen lies in the contents
of the working area.
The working area of a screen contains a list of programmable features
called “fields” that can be selected or changed using the arrow, Tab or
Return keys described on page 12.
On some screens, there are features that can be selected for each
individual channel or mode; these features are selected on a mode-by-
mode basis. On other screens, there are features that can be selected for
all modes of the radio (referred to as “radio-wide” features). And still
other screens list those features that perform specific RSS functions
such as servicing the radio or printing the personality data.
MOTOROLA Radio Service Software Use <: keys to scroll value.
HT/JT1000/VISAR Model : Use <Enter> to go to next feature.
Serial:
CHANGE:RADIO:SYS CONFIG
System Configuration
--------------------
Maximum Channel................16 Clear Chan Definition....Matched PL
Timeout Timer (sec)....... 60 Transmit LED................Enabled
Auto Reset Timer (sec).........10 Flashing LED.....Chan-Busy/Low-Batt
CS Sleep Period (ms)..........105 Quick Key Override..........Enabled
PL Sleep Period (ms)...........60 Tx Inhibit Monitor Func.....Enabled
AGC......................Disabled Battery Saver PL Lockout...Disabled
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP PRINT DEFAULT EXIT
