Print Receive Service
Menu
At the MAIN MENU, press F5, F2 and then F3 to bring up this menu.
The PRINT function is used to produce permanent records of codeplug
configurations. A printer is required and should be connected to your
computer according to the instructions in the user’s manual that came
with your computer. Graphics capability is NOT required.
Each print-out contains radio model and serial number information,
software version numbers, Radio Service Software version numbers,
and the date and time of the print-out. You must use the GET/SAVE
functions to first read or get a codeplug for printing radio
configuration data.
Note: When printing, misalignment of page breaks may result if
the printer is not set up properly. For best results, configure the
printer as an IBM ProPrinter or an Epson FX/MX having factory
default settings. The default number of lines per page is 66.
Function Key Descriptions
F2 - PRINT FEF Prints out Front-End Bandpass Filter Alignment information.
F3 - PRINT AUDIO Prints out Rated Audio Alignment information.
F4 - PRINT SQUELCH Prints out Squelch Alignment information.
F5 - PRINT XOVER Prints out VCO Crossover Alignment information.
F9 - PRINT ALL Prints out all the above service information modules.
EBC
MOTOROLA Radio Service Software Select a function key, F1-F10.
HT/JT1000/VISAR Model :
Serial:
PRT MAIN:SERVICE:RECEIVE
Print Receive Service Menu
--------------------------
F1 - HELP
F2 - Front End Bandpass Filter Alignment
F3 - Rated Audio Alignment
F4 - Squelch Alignment
F5 - VCO Crossover Alignment
F6 -
F7 -
F8 -
F9 - Print All the Above
F10 - EXIT
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP PRINT PRINT PRINT PRINT PRINT EXIT
FEF AUDIO SQUELCH XOVER ALL
