85
Side Button
Configuration
(VISAR only)
From the MAIN MENU, press F4 and then F3 twice to access this
screen.
This screen can be accessed for VISAR models only. It allows you to assign
functionality to the side buttons of a VISAR radio.
Function Key Descriptions
F5 - PRINT Prints the current system configuration.
F9 - DEFAULT Resets the fields on this screen to their default values.
Field Definitions
Sidebutton Functions Use the UP/DOWN arrow keys to select the functions for this button.
Not all functions are available on all models.
Note: The RSS will NOT allow side button functions to be duplicated
on more than one button, or allow you to duplicate a function that is
assigned to another control (for example, Scan on a side button
and Channel-Slaved Auto Scan in the same radi. If Scan is already
assigned to another control, Scan-related selections will not be
displayed among the choices.
The possible functions that can be assigned to Sidebuttons 1 and 2 are
detailed below:
DCC
MOTOROLA Radio Service Software Use <: keys to adjust value.
HT/JT1000/VISAR Model : H05SDD9AA4AN Use <Enter> key to go to next feature
Serial:
CHANGE:RADIO:SIDE BUTTON
Side Button Configuration
-------------------------
Sidebutton 1 function..................................Light Button
Sidebutton 2 function.......................................Monitor
Monitor Long Press Period (sec)...................................5
Permanent Monitor...........................................Enabled
Permanent Monitor Definition...........................Open Squelch
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP PRINT DEFAULT EXIT
Blank No function, no key chirp is sounded.
Monitor Radio will unsquelch when this button is pressed,
allowing you to listen to activity on the channel.
RAT An MDC Repeater Access Code will be transmitted
when this button is pressed.
