125
DTMF Phone List
(JT1000 and VISAR
Models only)
From the MAIN MENU, press F4, F3, F7, and then F5 to access this
screen.
This screen can be accessed only for models with DTMF keypads. Brings up
a screen from which you can configure DTMF options.
Function Key Descriptions
F2 - DTMF CONFIG This function will be visible only for VISAR models. Brings up a screen
from which you can configure additional DTMF options.
F5 - PRINT Prints the current system configuration.
F9 - DEFAULT Resets the fields on this screen to their default values.
Field Definitions
DTMF Tx Pre-Time Enter a value directly or use the UP/DOWN arrow keys to make your
selection. The is the time period that carrier or carrier with PL (if on a
PL channel) will be sent before the first DTMF digit is transmitted. The
value is expressed as a multiple of 25 ms, ranging from 25 ms to 6.375
seconds.
The default is 250 ms.
DTMF Digit Duration Enter a value directly or use the UP/DOWN arrow keys to make your
selection. This is the actual time duration for which DTMF tones are
transmitted on the channel for a single digit during auto-dial, or
manual dial if a timed tone duration is selected. The valid range is 4.12
to 1050.6 ms in 4.12-ms increments. A value of zero is NOT allowed.
The default is 152.44 ms.
DCGE
MOTOROLA Radio Service Software Use edit keys to modify entry.
HT/JT1000/VISAR Model : Use <Enter> to go to next feature.
Serial:
CHANGE:RADIO:SIG:DTMF
DTMF PHONE LIST
---------------
DTMF Tx Pre-Time.......... 250 ms DTMF Access Code..............8888
DTMF Digit Duration.....152.44 ms DTMF De-Access Code...........9999
DTMF Inter-Digit Delay..103.00 ms
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP DTMF PRINT DEFAULT EXIT
CONFIG
