23
scale is displayed indicating the minimum, maximum, and current
value of the softpot setting, as shown below:
Adjusting the softpot value sends information to the radio to increase
or decrease a DC voltage in the corresponding circuit. In all cases, the
softpot value is just a relative number, corresponding to a D/A (digital-
to-analog) generated voltage or digitally-controlled frequency in the
radio. All standard measurement procedures and test equipment are
applicable and are NOT affected in any way.
Function Key
Descriptions
F2 - TRANSMIT ALIGN
(Transmitter Alignment)
Used to perform standard radio transmit alignment procedures. Refer
to the appropriate Radio Service Manual for Transmit Alignment
procedures.
F3 - RECEIVE ALIGN
(Receiver Alignment)
Used to perform standard radio receive alignment procedures. Refer to
the appropriate Radio Service Manual for Receive Alignment
procedures.
F4 - SIGNAL ALIGN
(Signalling Alignment)
Used to perform standard radio signalling alignment procedures. Refer
to the appropriate Radio Service Manual for Receive Alignment
procedures.
F6 - TEST MODE Used to set up specific test conditions (TPL, DPL, MDC, etc.) on
specific test frequencies for a quick check of the radio transmit/receive
functionality.
F7 - CONTROLLER INIT
(Controller Board Initialization)
Used to initialize a replacement Controller Board with the radio serial
number that existed in the original factory-programmed board.
0
Min
255
Max
!
Caution
Transmitter, Receiver and Signalling Alignment
procedures should only be attempted by qualified
service personnel. Failure to perform alignment
procedures properly may result in a seriously degraded
radio or system performance. Refer to your Radio
Service Manual for detailed service procedures.
