Moxa Managed Ethernet Switch (UI_2.0_FW_5.x) User Manual
NOTE
If the Received is equal to or greater than 100 (times), then the status of ping tracking never changes
from down to up.
Lost
1 to 100
The threshold that the status of ping tracking changes f rom up
to down when the switch continuously loses the ping replies
greater than or equal to the lost value.
3
NOTE
If the Lost value is 100 (times), then the status of the Ping Tracking entry never changes f rom down to up.
Logic Tracking
Logic Tracking can monitor all of the tracking entries. There are three operator modes: NOT, AND, and OR.
With operator AND, if all the statuses of the entries in the Logical List are up, then the status of the logic
tracking entry is up. Otherwise, the status of the logic tracking entry is down. With operator OR, if all the
statuses of the entries in the Logical List are down, the status of the logic tracking entry is down. Otherwise,
the status of the logic tracking entry is up. Operator NOT means the status of the logic tracking entry will be
reversed after AND or OR logic operator.
Enable Logic Tracking
Select the Enable checkbox to enable logic tracking.
Enable
Disable Deselect the Enable checkbox to disable logic tracking.
Tracking ID
The tracking ID of the logic tracking f eature
NOTE
The Tracking ID has to be unique.
Logic List
Two to f our monitored tracking entries, and the logic tracking
ID must be bigger than all monitored tracking entries.
NULL
All of the existing
tracking entries
