Moxa Managed Ethernet Switch/Extender EDS Configurator GUI
Starting EDS Configurator
To start EDS Configurator, locate and run the executable file edscfgui.exe. There are two ways to do this:
• If the file was placed on the Windows desktop, it should appear as shown below. Simply double click the icon
to run the program.
• The Moxa EtherDevice Server Configurator window will open, as shown below.
You may download the EDS Configurator software free of charge from Moxa’s
Broadcast Search
Use the Broadcast Search utility to search the LAN for all Moxa switches that are connected to the LAN. Note
that since the search is done by MAC address. Broadcast Search will not be able to locate Moxa EtherDevice
switches connected outside the PC host’s LAN.
1. Start by clicking the Broadcast Search icon , or select Broadcast Search under the List Server menu.
The Broadcast Search window will open and display a list of all switches located on the network. Look in the
Progress column to see the progress of the search.
