6. The serial console will prompt you to log in. Press Enter and select admin or user. Use the down arrow key
on your keyboard to select the Password field and enter a password if desired. This password will be
required to access any of the consoles (web, serial, Telnet). If you do not wish to create a password, leave
the Password field blank and press Enter.
7. The Main Menu of the Moxa switch’s serial console should appear. (In PComm Terminal Emulator, you can
adjust the font by selecting Font… from the Edit menu.)
8. Use the following keys on your keyboard to navigate the Moxa switch’s serial console:
Key Function
Up, down, right, left arrow keys,
Tab
Move the onscreen cursor
Enter Display and select options
Space Toggle options
Esc Previous menu
Configuration by Telnet Console
Opening the Moxa switch’s Telnet or web console over a network requires that the PC host and Moxa switch are
on the same logical subnet. You may need to adjust your PC host’s IP address and subnet mask. By default, the
Moxa switch’s IP address is 192.168.127.253 and the Moxa switch’s subnet mask is 255.255.255.0 (referred to
as a Class B network). Your PC’s IP address must be set to 192.168.xxx.xxx if the subnet mask is 255.255.0.0,
or to 192.168.127.xxx if the subnet mask is 255.255.255.0.
