Moxa Managed Ethernet Switch/Extender Featured Functions
3-7
In standard mode, the connection speed is decided once the connection is established between the CO and the
CPE based on signal-to-noise ratio (SNR). However, the transmission speed will be auto detected from
5696Kbps to 15.3Mbps. It should take less than 5 minutes to complete the training process.
Setting Description Factory Default
Turbo mode status Indicates whether turbo mode is
enabled or not based on DIP
switch configuration
Disabled
Speed
Transmission speed can only be configured while Turbo mode is disabled. It shows the transmission speed
based on configuration.
Speed Description Factory Default
Auto Allows the port to use the ITU-T G.991.2 protocol to
negotiate with connected devices. The port and
connected devices will determine the best speed for
that connection
Auto
192K Manually assign one of these fixed speed options
Note: To provide reliable operation, connection may
not be able to be established if the SNR is less than
3dB. MOXA recommends manually assigning a
lower transmission speed or selecting auto mode
until the connection is established.
384K
512K
768K
1024K
1280K
2048K
2304K
2688K
3072K
3456K
4224K
4608K
4992K
5376K
5696K
Annex
ANNEX A and ANNEX B represent different transmission media types. ANNEX A is the US type cable (0.5mm;
e.g. 26AWG), and ANNEX B is the EU type cable (0.4mm; e.g. PE04). While the configuration of the DIP switch
(ANNEX B/ANNEX A) is the same as the media type, the transmission performance will be better when
compared to the cross configuration.
Setting Description Factory Default
Device communication media
type
Display the media type
ANNEX A is the US type, ANNEX
B is the EU type
ANNEX B(EU)
LED Status
The DSL Ethernet Extender supports two parameters displayed on the DSL SPEED/SNR LED indicator. One is
transmission speed and the other is the signal-to-noise ratio (SNR) of the connection. By selecting the
hardware DIP switch, SNR/SPEED reflects what will be displayed for DSL SPEED/SNR LED indicator on device
front panel.
Setting Description Factory Default
LED indicator status Displays DSL SPEED/SNR LED
indicator status based on DIP
switch configuration
SNR
