IP4
The IPv4 settings include the switch’s IP address and subnet mask, as well as the IP address of the default
gateway. In addition, input cells are provided for the IP addresses of a 1st and 2nd DNS server.
Auto IP Configuration
Setting Description Factory Default
Disable The Moxa switch’s IP address must be set manually. Disable
By DHCP The Moxa switch’s IP address will be assigned automatically by
the network’s DHCP server.
By BootP The Moxa switch’s IP address will be assigned automatically by
the network’s BootP server.
Switch IP Address
Setting Description Factory Default
IP address for the Moxa
switch
Assigns the Moxa switch’s IP address on a TCP/IP network. 192.168.127.253
Switch Subnet Mask
Setting Description Factory Default
Subnet mask for the
Moxa switch
Identifies the type of network the Moxa switch is connected to
(e.g., 255.255.0.0 for a Class B network, or 255.255.255.0 for
a Class C network).
255.255.255.0
Default Gateway
Setting Description Factory Default
IP address for gateway
Specifies the IP address of the router that
connects the LAN to
an outside network.
None
DNS IP Address
Setting Description Factory Default
IP address for DNS
server
Specifies the IP address of the DNS server used by your
network. After specifying the DNS server’s IP address, you can
use the Moxa switch’s URL (e.g., www.PT.company.com) to
open the web console instead of entering the IP address.
None
IP address for 2nd DNS
server
Specifies the IP address of the secondary DNS server used by
your network. The Moxa switch will use the secondary DNS
server if the first DNS server fails to connect.
None
DHCP Retry Periods
Setting Description Factory Default
1 to 30 Users can configure the DHCP retry period manually 1
DHCP Retry Times
Setting Description Factory Default
0 to 65535 Users can configure the times of DHCP retry manually 0
IP6
The IPv6 settings include two distinct address types—Link-Local Unicast addresses and Global Unicast
addresses. A Link-Local address makes the switch accessible over IPv6 for all devices attached to the same
local subnet. To connect to a larger network with multiple segments, the switch must be configured with a
Global Unicast address.
