Moxa Technologies Managed Ethernet Switch/Extender User Manual

Moxa Managed Ethernet Switch/Extender Featured Functions
3-32
Enable Enables the SNMP trap function of PoE warning Disable
Disable Disables the SNMP trap function of PoE warning
Relay Output
Setting Description Factory Default
Enable Enables the relay output function of PoE warning Disable
Disable
Disables the relay output function of PoE warning
Email
Setting Description Factory Default
Enable Enables the email alarm function of PoE warning Disable
Disable Disables the email alarm function of PoE warning
Event Type
Port Events Description
PoE port power on Power outputs to PD
PoE port power off Cut off PoE power output
PoE port over-current/short-circuit When the current of the port exceeds the limitation:
802.3 af – 350mA
802.3 at – 600mA
High Power – 720mA
Force – 600mA
PD Failure Check (no response) When the switch cannot receive a PD response after the defined
period
Exceed PoE system threshold When sum of all PD power consumption exceeds the threshold of
total PoE power output
External FET has failed When the MOSFET of the port is out of order, please contact Moxa
for technical service
PSE chip is over temperature Please check the environmental temperature. If it is over 75
o
C,
please operate the switch at an adequate temperature. If not,
please contact Moxa for technical service.
V
EE
(PoE input voltage) under voltage
lockout
The voltage of the power supply drops down below 44VDC.
Adjust the voltage between 46 and 57VDC to eliminate this issue.
NOTE
The
Relay Output does not support three Event Types: External FET has failed, PSE chip is over
temperature
, and V
EE
(PoE input voltage) under voltage lockout.
