Moxa Managed Ethernet Switch/Extender Featured Functions
3-46
Port PVID
Setting Description Factory Default
VID ranges from 1 to
4094
S
ets the default VLAN ID for untagged devices that connect to
the port.
1
Fixed VLAN List (Tagged)
Setting Description Factory Default
VID ranges from 1 to
4094
This field will be active only
when selecting the Trunk or Hybrid
port type. Set the other VLAN ID for tagged devices that
connect to the port. Use commas to separate different VIDs.
None
Fixed VLAN List (Untagged)
Setting Description Factory Default
VID range from 1 to
4094
This field will be active only when selecting the Hybrid
port type. Set the other VLAN ID for tagged devices that
connect to the port and tags that
need to be removed in egress
packets. Use commas to separate different VIDs.
None
Forbidden VLAN List
Setting Description Factory Default
VID ranges from 1 to
4094
This field will be active only when selecting the Trunk or Hybrid
port type. Set the other
VLAN IDs that will not be supported by
this port. Use commas to separate different VIDs.
None
Port-Based VLAN Settings
Check each specific port to assign its VLAN ID in the table. The maximum VLAN ID is the same as your number
of switch ports.
