Moxa Managed Ethernet Switch/Extender Featured Functions
3-57
Type 1
Traffic Rate Limiting Settings
Control Mode Description Factory Default
Normal Set the max. ingress rate limit for different packet types
Normal
Port Disable When the ingress multicast and broadcast packets exceed the
ingress rate limit, the port will be disabled for a certain period.
During this period, all packets from this port will be discarded.
Ingress Rate Limit - Normal
Policy Description Factory Default
Limit All
Select the ingress rate limit for different
packet types from the following options:
Not Limited, 128K, 256K, 512K, 1M, 2M,
4M, 8M
Limit Broadcast 8M
Limit Broadcast, Multicast, Flooded Unicast
Limit Broadcast, Multicast
Limit Broadcast
Ingress Rate Limit – Port Disable
Setting Description Factory Default
Port disable duration (1~65535
seconds)
When the ingress multicast and broadcast packets
exceed the ingress rate limit, the port will be
disabled
for this period of time. During this time, all packets
from this port will be discarded.
30 second
Ingress (fps)
Select the ingress rate (fps) limit for all packets from
the following options: Not Limited, 4464, 7441,
14881, 22322, 37203, 52084, 74405
Not Limited
