Moxa Managed Ethernet Switch/Extender Featured Functions
3-59
Ingress and Egress Rate Limit - Normal
Setting Description Factory Default
Ingress rate Select the ingress/egress rate limit (% of max.
throughput) for all packets from the following options:
Not Limited, 3%, 5%, 10%, 15%, 25%, 35%, 50%,
65%, 85%
Not Limited
Egress rate
Ingress Rate Limit – Port Disable
Setting Description Factory Default
Period (1~65535 seconds) When the ingress packets exceed the ingress rate limit,
the port will be disabled for a certain period.
30 seconds
Ingress (frame per second) Select the ingress rate (fps) limit for all packets from the
following options: Not Limited, 4464, 7441, 14881,
22322, 37203, 52084, 74405
Not Limited
Unicast Filter Behavior
NOTE: These functions are supported in the EDS-728/828 and rackmount switches.
When a switch receives an unknown unicast packet, it will flood it to all ports in the LAN. The Unicast Filter
Behavior function provides a mechanism to prevent switch flooding of these unknown unicast packets. Select
this check box to activate this filter behavior.
Setting Description Factory Default
Enable Filter
unknown
Unicast
Enable this function to prevent unknown unicast packets
from flooding to all ports in the VLAN
Disable
