Moxa Managed Ethernet Switch/Extender Featured Functions
3-72
Server IP Address
1st Server
Setting Description Factory Default
IP address for the 1st
DHCP server
Assigns the IP address of the 1st DHCP server that the switch
tries to access.
None
2nd Server
Setting Description Factory Default
IP address for the 2nd
DHCP server
Assigns the IP address of the 2nd DHCP
server that the switch
tries to access.
None
3rd Server
Setting Description Factory Default
IP address for the 3rd
DHCP server
Assigns the IP address of the 3rd DHCP server that the switch
tries to access.
None
4th Server
Setting Description Factory Default
IP address for the 4th
DHCP server
Assigns the IP address of the 4th DHCP server that the switch
tries to access.
None
DHCP Option 82
Enable Option 82
Setting Description Factory Default
Enable or Disable
Enable or disable the DHCP Option 82 function.
Disable
Type
Setting Description Factory Default
IP Uses the switch’s IP address as the remote ID sub. IP
MAC Uses the switch’s MAC address as the remote ID sub. IP
Client-ID
Uses a combination of the switch’s MAC address and IP address
as the remote ID sub.
IP
Other Uses the user-designated ID sub. IP
Value
Setting Description Factory Default
Max. 12 characters Displays the value that was set. Complete this field if type is set
to Other.
Switch IP address
Display
Setting Description Factory Default
read-only The actual hexadecimal value configured in the DHCP server for
the Remote-ID. This value is automatically generated
according to the Value field. Users cannot modify it.
COA87FFD
DHCP Function Table
Enable
Setting Description Factory Default
Enable or Disable Enable or disable the DHCP Option 82 function for this port. Disable
