User Manual
Figure 5-55: Wave Record Menu of External Storage
Record menu (External Storage) shows as follows:
Close wave record function
Set record menu
Turn the M rotary control to select the number of
frames to record (1 - 1000)
Turn the M rotary control to select the interval
between recorded frames (1ms - 1000s)
Record infinitely until the storage medium is full
Refresh wave during recording
Stop refreshing
Begin to record
Stop recording
Note:
Both of the waveforms of Channel 1 and Channel 2 will be recorded. If a Channel is
turned off while recording, the waveform of the channel is invalid in the playback mode.
