MUTOH Rockhopper 3 User Manual

Troubleshooting
13 AP-74700 – Rev. 1.0 – 10/03/2008
(3) If initialization
does not take effect
when the head unit is
initialized, the
Mainboard assembly
may be damaged.
• Replace the
Mainboard
assembly.
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV board
assembly and
cooling fan
assembly
(1) Check the
connections of
connectors.
• Redo the
connections of
the following
connectors.
• Mainboard : J102
• power source
board (small)
assembly : CN51
– CN52
(2) The
HDD_MOTHER
board assembly may
be damaged.
• Replace the ink
tube.
• Initializing CR
motor history.
(3) Hard disk may be
damaged.
• Replace the hard
disks.
11 Hard disk status
connect error
There is a problem in
the hard disk
connections.
(4) The Mainboard
assembly may be
damaged.
• Replace the
Mainboard
assembly.
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV board
assembly and
cooling fan
assembly.
→ Replacing the
power source board
assembly.
(1) The PCI_LINUX
board assembly may
be damaged.
• Replace the
PCI_LINUX board
assembly.
12 Network
initialize error
There is a problem in
the network board.
(2) The Mainboard
assembly may be
damaged.
• Replace the
Mainboard
assembly.
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV board
assembly and
cooling fan
assembly.
(1) Check if the
waste bottle has
been installed.
• Install the waste
bottle correctly.
-
(2) Check the
operation of the
waste box sensor
assembly via
“Sensor/Waste Bin”
of the self-diagnostic
function.
• Replace the
waste box sensor
assembly.
-
(3) Check the
connections of the
connectors.
• Check if the
waste box sensor
connectors are
connected to the
rear side cap R.
• Redo the
connections of
the following
connectors.
• Mainboard : J120
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV board
assembly and
cooling fan
assembly.
13 Waste ink tank
sts. No
The waste tank is not
installed.
(4) The Mainboard
assembly may be
damaged.
• Replace the
Mainboard
assembly.
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV board
assembly and
cooling fan
assembly.
