Installation and Operation Manual
●
EZvav Digital Controls
FloangReheat
This applicaon is for a BAC-8005-36 controller. Use the oang reheat opon in hydronic systems that are controlled by an
actuator with tri-state inputs. The reheat outputs are triacs that can switch up to 1 ampere at 24 volts AC.
For cooling and heang, a duct temperature sensor is required for Discharge Air Temperature liming and automac changeover.
See the topic Advanced opons on page 21 for instrucons to enable Discharge Air Temperature liming.
When connecng the controller to a fan powered VAV unit, the fan circuits must be compable with the following specicaons.
• The fan start circuit is a 24 volt AC pilot duty output.
• The fan speed output is 0 – 10 volts DC.
Submial sheets for several variaons of this applicaon are available from the Resources page at www.nailor.com.
Figure7-4 Floangreheat
ON CTS
1 2
COMM
READY
AI1
AI5
GND
AO4
AO3
SC
BO8
BO5
BO6
SC
BO7
24VAC
AI6
GND
AI7
T-STAT/
SENSOR
-A
+B
S
EOL
BACnet MS/TP
Fan
Speed
Duct
Temp
Sensor
24VAC
Fan start
24 VAC
24VAC THERMAL
ACTUATOR
