Installation and Operation Manual
●
EZvav Digital Controls
Specicaons
EZvav specicaons are subject to change without noce.
Inputsandoutputs
All inputs and outputs are factory programmed and applicaon specic. No eld conguraon is required. For details on input and
output connecons, see the topic Applicaon drawings on page 29. For a detailed lisng of input and output objects, see the topic
BACnet objects on 44.
Analoginputs
Analog inputs represent BACnet analog input. Not all input are applicable or required for all models.
Key features IP/SI standard units of measure.
Overvoltage input protecon
Connectors RJ-45 room sensor jack
Screw terminals for wire sizes 12 – 26 AWG
Conversion 12 – bit analog–to–digital conversion
Input range Passive, 10 kΩ pull-up to 3.3 volts DC
Analogoutputs
Analog outputs are congured to represent BACnet analog output objects. No eld conguraon is required. For details on
applicaon specic output connecons see the secon Applicaon drawings on page 29.
Key features Output short protecon
IP/SI standard units of measure
Connector Screw terminals for wire size 12 – 26 AWG
Conversion 12 – bit digital-to-analog conversion
Output voltage 0 – 10 VDC
Output current 30 mA per output, 30 mA total for all analog outputs
Binaryoutputs
Binary outputs are congured to represent BACnet binary output objects. No eld conguraon is required. For details on
applicaon specic output connecons see the secon Applicaon drawings on page 29.
Key features Opcally isolated triac output
Connector Screw terminals for wire size 12 – 26 AWG
Output range Maximum switching 24 Volts AC
1 ampere per external output, 3 amperes total
Communicaons—BACnetMS/TP
• EIA – 485 operang at rates up to 76.8 kilobaud.
• Removable screw terminal block.
• Wire size 12 – 26 AWG.
• Switch selected end of line terminaon.
Memory
• Programs and program parameters are stored in nonvolale memory.
• Auto restart on power failure.
Airowsensorfeatures
• Congured as BACnet analog input object.
• CMOS dierenal pressure 0 – 2 inches of water (0 – 500 Pa) measurement range. Internally linearized and temperature
compensated.
• Span accuracy 4.5% of reading.
• Zero point accuracy 0.0008 in. H2O/0.2 Pa at 77°F (25°C).
• Barbed connecons for 1/4 inch (6.35 mm) FR tubing.
