Installation and Operation Manual
●
EZvav Digital Controls
SafetyConsideraons
Nailor assumes the responsibility for providing you a safe product and safety guidelines during its use. Safety means protecon to
all individuals who install, operate, and service the equipment as well as protecon of the equipment itself. To promote safety, we
use hazard alert labeling in this manual. Follow the associated guidelines to avoid hazards.
Note: Notes provide addional informaon that is important.
Tip: Provides programing ps and shortcuts that may save me.
Secon2:InstallingtheControllers
This secon provides important instrucons and guidelines for installing the Nailor EZvav controllers. Carefully review this
informaon before installing the controller.
Installing Nailor EZvav includes the following topics that are covered in this secon.
Installaon topics in this secon
Seng the rotaon limits ...................................................................................................................7
Mounng on a VAV terminal box ........................................................................................................8
Connecng an airow sensor .............................................................................................................9
Connecng inputs and outputs ..........................................................................................................9
Connecng room temperature sensors ..............................................................................................9
Connecng a DAT sensor ..................................................................................................................10
Connecng power.............................................................................................................................10
Maintenance .....................................................................................................................................10
SengtheRotaonLimits
Nailor EZvav controllers are manufactured for a damper that rotates 90 degrees from open to close. If the VAV damper is not a 90
degree damper, set the rotaon limits to 45 or 60 degrees before mounng the controller.
DANGER represents the most severe hazard
alert. Bodily harm or death will occur if danger
guidelines are not followed.
CAUTION indicates potenal personal injury or
equipment or property damage if instrucons
are not followed.
WARNING represents hazards that could result
in severe injury or death.
CAUTION Seng rotaon limits that do not
match the VAV damper may result in improper
operaon or equipment damage.
