Installation and Operation Manual
●
EZvav Digital Controls
BACnet Objects
The EZvav controllers are BACnet Applicaon Specic Controller (ASC) that are composed of standard BACnet objects. This secon
lists the objects that are likely to be monitored by a standard BACnet operator workstaon to verify system operaon.
Input objects
The following BACnet input objects represent values at the physical inputs of the controller. For wiring details, see the topic
Applicaon drawings on page 29.
Table9–2 Inputobjects
Input Name Descripon ObjectType
AI1 DISCHARGE AIR Discharge Air Temperature KMC10K_Type_III
AI2 SPACE SENSOR Space Sensor KMC Type II Deg F
AI3 SPACE SET POINT Space Set point TABLE_4
AI4 PRIMARY DUCT Primary Duct Pressure
AI5 SECONDARY DUCT Secondary Duct Pressure
Output objects
The following BACnet output objects represent values at the physical outputs of the controller. For applicaon specic output
wiring details, see the topic Applicaon drawings on page 29.
Table9–3 Outputobjects
Output Name Descripon Unit
AO3 ANALOG HEAT Analog Heat 0_100%
AO4 FAN SPEED Fan Speed 0_100%
BO1 DAMPER CW Damper Clockwise
BO2 DAMPER CCW Damper Counter Clockwise
BO5 FAN Fan
BO6 HT STAGE 1 Heang Stage 1
BO7 HT STAGE 2 Heang Stage 2
BO8 HT STAGE 3 Heang Stage3
Valueobjects
BACnet value objects represent set points or other operaonal condions in the controller.
Note: Not all objects are present in every model.
Table9–4 Analogvalueobjects
Object Name Descripon
AV1 SPACE TEMP Space Temperature
AV2 STPT REFERENCE Set point Reference
AV3 ACT COOL STPT Acve Cooling Set point
AV4 ACT HEAT STPT Acve Heang Set point
AV5 OCC CL STPT Occupied Cooling Set point
AV6 OCC HT SPT Occupied Heang Set point
AV7 UNOCC CL STPT Unoccupied Cooling Set point
CAUTION Choosing RSTR deletes all previously
congured values including balancing values and
passwords. Only the BACnet communicaons
sengs will remain unchanged.
