NAiS FP1 User Manual

■ Memory area
■ External input relay (X), external output relay
(Y), internal relay (R)
• The lowest digit for these relay's X, Y, and R numbers
is expressed in hexadecimals and the second and
higher digits are expressed in decimal to enable both
bit and word processing.
■ Timer contact (T), counter contact (C)
• The timer contact (T) and counter contact (C) numbers are expressed in decimal.
Timer contact (T) Counter contact (C)
T
Decimal
0, 1, 2
...................................
99
C
Decimal
100, 101
...............................
143
R
Decimal
]
, 1, 2, 3
...........................
12
.......
Hexadecimal
0, 1, 2, 3
........
9, A, B,
........
F
Y
X
C14 and
C16 series
256 points
(R0 to R15F)
28 points
(C100 to C127)
C24, C40, C56,
and C72 series
1,008 points
(R0 to R62F)
44 points
(C100 to C143)
Numbering
208 points
(X0 to X12F)
208 points
(Y0 to Y12F)
64 points
(R900 to R903F)
100 points
(T0 to T99)
External input relay (X)
External output relay (Y)
Internal relay (R)
Special internal relay (R)
Timer contact (T)
Counter contact (C)
Relay
Timer/
Counter
contact
Item
64
4-2. How to Program the Programmable Controller
X0, X1, X2, X3, X4, X5, X6, X7, X8, X9, XA, XB, XC, XD, XE, XF
X10,
.......................................................................................
X1F
X20,
.......................................................................................
X2F
X90,
.......................................................................................
X9F
X100,
...................................................................................
X10F
X110,
...................................................................................
X11F
X120,
...................................................................................
X12F
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Example:
Relay number
