4-4. Programming with the FP Programmer II
2. Downloading a Program to the Programmable Controller
Procedure
1. Connect FP Programmer II and the FP1 programmable controller using the FP1 Peripheral Cable.
2. Set the mode selector of the FP1 to PROG.
3. Press the keys on the FP Programmer II, as shown on the right, to clear all
the data stored in the FP1 programmable controller.
4. Enter the address from where you want to enter instructions. Use the
alphanumeric keys to enter the address. In the example, instructions are
entered from address 0, therefore, press to read its contents then press .
5. Download the program (addresses and instructions) to the programmable controller.
Notes:
• An alarm will sound if you try to download a program while in RUN mode or if you press the wrong keys.
If an alarm sounds, press the key and redo the download operation from the beginning.
• The first time you input a program, be sure to execute the program clear procedure (step 3, above) before
starting input.
