Type
FP Programmer II
FP1 Peripheral Cable
Part number
AFP1114
AFP15205
AFP1523
Description
Handheld programming device for FP Series
programmable controllers
Cable needed for connection between the
Control Unit’s RS422 port and the FP
Programmer II’s communication port.
0.5 m/1.640 ft.
3 m/9.843 ft.
Type
FP1 Transmitter
Master Unit
FP1 I/O Link Unit
C-NET Adapter
C-NET Adapter
S1 type
(for FP1 Control
Unit only)
Operating voltage
24 V DC
100 V to 240 V AC
24 V DC
100 V to 240 V AC
24 V DC
100 V to 240 V AC
Part number
AFP1752
AFP1756
AFP1732
AFP1736
AFP8532
AFP8536
AFP15401
Specification
FP1 Transmitter Master Unit enables the FP1
to exchange I/O information with slave stations
at a remote site using a twisted pair cable. By
connecting with another FP1 Transmitter
Master Unit or with an FP3 Transmitter Master
Unit, you can exchange I/O information with
another FP1. Communication medium (RS485
port): Twisted pair cable up to 32 inputs and
32 outputs can be controlled per unit.
The FP1 I/O Link Unit is the interface unit for
exchanging I/O information between an
FP3/FP5 and an FP1.
When the FP1 is connected to the FP3/FP5
Remote I/O System via the FP1 I/O Link Unit,
you can exchange I/O information,
using a 2-conductor cable.
RS485 ↔ RS422/RS232C signal converter.
Used for communication between the
programmable controller and your computer.
Communication medium (RS485 port):
2-conductor cable or twisted pair cable
RS485 ↔ RS422 signal converter for FP1
Control Unit.
Used for communication between the C-NET
Adapter and FP1 Control Unit.
Type
FP1 A/D
Converter Unit
FP1 D/A
Converter Unit
Specification
• Analog input points:
• Analog input range:
• Digital output range:
• Analog input points:
• Analog input range:
• Digital output range:
Operating voltage
24 V DC
100 V to 240 V AC
24 V DC
100 V to 240 V AC
Part number
AFP1402
AFP1406
AFP1412
AFP1416
4 channels/unit
0 to 5 V, 0 to 10 V, 0 to 20 mA
K0 to K1000
2 channels/unit
0 to 5 V, 0 to 10 V, 0 to 20 mA
K0 to K1000
