VS1 Operations and Maintenance Manual Operating the transmitter
Issue 3.1 2013-10-01 Page 2-113
Connecting a Laptop Directly to the Transmitter
If connecting to the VS1 directly with a laptop, you must set a static IP address on the VS1 and your
laptop.
1. From the front panel UI’s Main Menu, go to User Settings -> Network Settings and set
the IP address as follows:
• DHCP: OFF
• IP Address: 10.10.10.2
• Netmask: 255.255.255.0
2. Set the transmitter for Remote control.
3. On the laptop, go to Start Menu/Control Panel/Network Connections/Local Area
Network
.
4. In the Local Area Network Status, open the General tab and choose Properties. Scroll down
and highlight Internet Protocol (TCP/IP). Choose Properties.
5. In the Internet Protocol (TCP/IP) Properties window, select Use the following IP address.
6. Enter the following settings:
• IP Address: 10.10.10.1
• Subnet Mask: 255.255.255.0
• Default Gateway: 192.168.1.2
7. In the Internet Protocol (TCP/IP) Properties window, select OK.
8. In the Local Area Connection Properties window, select
OK.
9. In the Local Area Connection Status window, select Close.
10. Close the Network Connections window.
Note:
The following steps assume the operating system is Windows XP. Adapt as required for
computers with different operating systems.
